Model: 96343C6A

Finish: Chrome

Dimensions

• 308 mm height with handle closed (330 mm maximum handle envelope); 231 mm outlet clearance; 155 mm outlet reach; 50 mm diameter base.

Technical information

• Cartridge size: 25mm
• Cartridge type: Ceramic Disc Cartridge
• Coating method: Chromeplated
• Manufacturer product type: Tower Basin Mixers
• Components and installation: Cartridge size: 25mm.
• Components and installation: 34-36 mm tap hole per the attached manual.
• Components and installation: Manufacturer supply limits: 150-1000 kPa, with the sheet specifying a 500 kPa maximum outlet pressure for new installations;
• Components and installation: balance hot/cold pressures.
• Components and installation: Maximum hot-water temperature 80°C per the linked sheet.
• Maximum hot water temperature c — Value: 80.0
• Manufacturer supply pressure kpa — Minimum: 150
• Manufacturer supply pressure kpa — Maximum: 1000

• Current manufacturer replacement-page observation;legacy stock batch not independently matched. Do not assert lead-free or new registration.

Installation

• Install by a licensed plumber in accordance with the linked manufacturer instructions. Flush pipework before connection; inspect the finish/components and test for leaks after installation. Deck mounted: maximum deck thickness 40 mm; 34-36 mm tap hole per the attached manual. Fit hot/cold isolation valves and keep flexible tails free of kinks, twist and tension. Manufacturer supply limits: 150-1000 kPa, with the sheet specifying a 500 kPa maximum outlet pressure for new installations; balance hot/cold pressures. Maximum hot-water temperature 80°C per the linked sheet. Not suitable for gravity-fed supply. Check water-heater and tempering-valve compatibility before fitting low-flow tapware/showers. Clean using a soft cloth and warm soapy water. Avoid abrasive cleaners, harsh chemicals, chlorides and acids; keep aerators and shower nozzles clean.

Water efficiency

• WELS rating: 6 Star
• Flow rate: 4.5 L/min
• WELS registration: T36492

Caroma Version 16 (effective 1 April 2026):20 years replacement product/parts,10 years Tapware Engine parts where applicable, and 1 year labour. 20 years for this Chrome finish. Wall fixings, mounting brackets, shower sliders, soap dishes and metal flex hoses are limited to 12 months parts. Manufacturer conditions, purchase-date eligibility and proof of purchase apply; Australian Consumer Law rights remain.

CLEARANCE STOCK — No returns or refunds for change of mind. Your rights under the Australian Consumer Law are not excluded.

Materials

• Brass

Care

• Clean using a soft cloth and warm soapy water. Avoid abrasive cleaners, harsh chemicals, chlorides and acids; keep aerators and shower nozzles clean.
